CHAIN SPROCKETS FOR ROLLER CHAINS 1
The range of sprockets designed for chains manufactured by our Company provides an all-round solution to the ne- eds of industry in the sector of flexible mechanical tran- smissions and is the result of a manufacturing process that is designed to achieve the top in terms of technical and quality performance.
Our production programme includes sprockets and whe- els designed for chains, produced in compliance with the principles and with the most recent Standards and Interna- tional Unified Standards: UNI, ISO, DIN, ANSI, etc. However, the standards define a profile with minimum dimensions and a profile with maximum dimensions for the wheel space for chains and rollers and the actual profi- le must lie within these values.
There is the option of selecting proportioning criteria for the profile, since the tolerances that the Standards leave to the manufacturer’s discretion are quite wide. The profiles can be optimised in terms of smooth transmission and the tooth’s capacity to support greater stresses. This has led to the systematic development of a series of standardised profiles for which the geometry can be reproduced with great precision by tools designed specifically by compu- ter and the reference profile of which is protected by the Company’s knowhow.
A valued feature of this optimised profile, which is a cha- racteristic exclusive to CHIARAVALLI GROUP SpA, is that of enhancing the “polygonal” chain wrap-around on the sprocket and on the platewheel, reproducing the motion discontinuity which is achieved even in the case of unfa- vourable transmission ratios and centre distances.
As a result of this CHIARAVALLI GROUP SpA has been able to include sprockets with a very low number of teeth in its catalogue and production programme.
Respecting precision with limited machining errors is beneficial, even if the toothed wheel-chain set represents a somewhat “basic” transmission solution.
This precision is assured by the systematic use of CNC ma- chines and technologies developed to minimise the she- aring stress and to improve the degree of surface finish. The sprockets and wheels designed for chains included in the catalogue are also manufactured in the version with the “Taperlock” taper bush piece system particularly fa- voured in applications that require easy assembly and very precise centring tolerances.
Our sales programme is completed with single and multi- ple roller chains, and special chains suitable for every in- dustrial application and CHIARAVALLI GROUP SpA is also able to manufacture sprockets and platewheels suitable for chains in a specific execution, produced to drawing any of material and with induction hardening and case-harde- ning and hardening applied to steel wheels and sprockets.
4 CHAIN SPROCKETS ISO
for roller chains in compliance with DIN 8187 - ISO/R 606
5 x 2.5 mm C
r
CHAIN SPROCKETSCHAINPitch 5 mmCHAIN SPROCKETSSprockets tooth width B1 2,6 mm h1/4” x 1/8” CCHAIN SPROCKETSCHAINPitch 6,35 mmCHAIN SPROCKETSSprockets tooth width B1CHAINPitch 8 mm3/8” x 7/32” CCHAIN SPROCKETSSprockets tooth width B1 5,3 mm Sprockets tooth width b1 5,2 mm Sprockets tooth width B2 15,4 mm Sprockets tooth width B3 25,6 mmFOR MONOLITHIC CHAIN SPROCKETSSprockets tooth width B11/2” x 3/16” CCHAIN SPROCKETSCHAINPitch 12,7 mmCHAIN SPROCKETSCHAINPitch 12,7 mm1/2” x 1/4” rullo 8.51 CCHAIN SPROCKETSCHAINPitch 12,7 mmCHAIN SPROCKETSSprockets tooth width B1 7,2 mm Sprockets tooth width b1 7 mm Sprockets tooth width B2 21 mm Sprockets tooth width B3 34,9 mmFOR MONOLITHIC CHAIN SPROCKETSFOR MONOLITHIC CHAIN SPROCKETSSprockets tooth width B1 11,1 mm Sprockets tooth width b1 10,8 mm Sprockets tooth width B2 30,3 mm Sprockets tooth width B3 49,8 mmFOR MONOLITHIC CHAIN SPROCKETS1” x 17.02 mm CCHAIN SPROCKETSSprockets tooth width B1 16,2 mm Sprockets tooth width b1 15,8 mm Sprockets tooth width B2 47,7 mm Sprockets tooth width B3 79,6 mmFOR MONOLITHIC CHAIN SPROCKETSSprockets tooth width B1 18,5 mm Sprockets tooth width b1 18,2 mm Sprockets tooth width B2 54,6 mm Sprockets tooth width B3 91 mmFOR MONOLITHIC CHAIN SPROCKETS1” 1/2 x 1” CCHAIN SPROCKETSSprockets tooth width B1 24,1 mm Sprockets tooth width b1 23,6 mm Sprockets tooth width B2 72 mm Sprockets tooth width B3 120,3 mmFOR MONOLITHIC CHAIN SPROCKETSCHAIN SPROCKETSSprockets tooth width B1 29,4 mm Sprockets tooth width b1 28,8 mm Sprockets tooth width B2 88,4 mm Sprockets tooth width B3 148 mmFOR MONOLITHIC CHAIN SPROCKETS2” x 1” 1/4 CCHAIN SPROCKETSSprockets tooth width B1 29,4 mm Sprockets tooth width b1 28,8 mm Sprockets tooth width B2 87,4 mm Sprockets tooth width B3 146 mmFOR MONOLITHIC CHAIN SPROCKETSCHAINPitch 9,525 mmpitch 1/2” x 5/16” CCHAIN SPROCKETSSprockets tooth width B1 7,4 mm Sprockets tooth width b1 7,2 mm Sprockets tooth width B2 21,6 mm Sprockets tooth width B3 36 mmPitch 15,875 mmpitch 3/4” x 1/2”CHAIN SPROCKETSSprockets tooth width B1 12 mm Sprockets tooth width b1 11,8 mm Sprockets tooth width B2 34,6 mm Sprockets tooth width B3 57,4 mmSprockets tooth width B1 15 mm Sprockets tooth width b1 14,7 mm Sprockets tooth width B2 44 mm Sprockets tooth width B3 73,3 mmpitch 1” 1/4 x 3/4” CCHAIN SPROCKETSSprockets tooth width B1 18 mm Sprockets tooth width b1 17,7 mm Sprockets tooth width B2 53,5 mm Sprockets tooth width B3 89,2 mmSprockets tooth width B1 24,1 mm Sprockets tooth width b1 23,6 mm Sprockets tooth width B2 69 mmAISI 304 LAISI 304 LAISI 304 L3/8” x 7/32” 06B-1CHAIN SPROCKETSSprockets tooth width B15,3 mm = APitch 9,525 mmCHAIN SPROCKETSSprockets tooth width B15,3 mm = APitch 9,525 mm1/2” x 5/16” 08B-1CHAIN SPROCKETSSprockets tooth width B17,2 mm =Pitch 12,7 mmCHAIN SPROCKETSSprockets tooth width B17,2 mm = APitch 12,7 mm5/8” x 3/8” 10B-1CHAIN SPROCKETSSprockets tooth width B19,1 mm = APitch 15,875 mmCHAIN SPROCKETSSprockets tooth width B19,1 mm = APitch 15,875 mm3/4” x 7/16” 12B-1CHAIN SPROCKETSSprockets tooth width B111,1 mm = APitch 19,05 mmCHAIN SPROCKETSSprockets tooth width B111,1 mm = APitch 19,05 mm1” x 17.02 16B-1CHAIN SPROCKETSSprockets tooth width B116,2 mm = APitch 25,4 mmCHAIN SPROCKETSSprockets tooth width B116,2 mm = APitch 25,4 mmC 45 UNI 5007GG20 UNI 5007C 45 UNI 5007GG20 UNI 5007C 45 UNI 5007GG20 UNI 5007C 45 UNI 5007GG20 UNI 50073/8” x 7/32”for roller chains in compliance with DIN 8187 ISO/R 6061/2” x 5/16”for roller chains in compliance with DIN 8187 ISO/R 606for roller chains in compliance with DIN 8187 ISO/R 606for roller chains in compliance with DIN 8187 ISO/R 606We do not manufacture SPROCKETS in cast iron version ASACHAIN SPROCKETS AWe do not manufacture SPROCKETS in cast iron version ASAALL THE CHAIN SPROCKETS FOR TRANSPORTERS AND ELEVATORS ARE REALIZED WITH WELDED HUB.WITH BEARING AWITH ECONOMIC BEARING A
