i T2n

CHPL

(daNm)

OUT IN

2501 3.78 ÷ 7.25 126.4 ÷ 256.5

2502 13.4 ÷ 62.8 126.4 ÷ 256.5

2503 52.1 ÷ 424.1 126.4 ÷ 256.5

2504 352.0 ÷ 2369.2 162.5 ÷ 256.5

Ø65

Ø75

58X53 DIN 5482

58X53 DIN 5482

Ø42 Ø65

Electric Motor

Brake

Hydraulic Motor

Worm gearboxes

i T2n

(daNm)

OUT IN

2502 12.1 ÷ 21.3 126.4 ÷ 232.8

2503 39.4 ÷ 143.5 126.4 ÷ 256.5

2504 140.1 ÷ 1244.1 126.4 ÷ 256.5

Ø65

Ø75

58X53 DIN 5482

58X53 DIN 5482

Ø42 Ø65

Electric Motor

Brake

CHPLB

Hydraulic Motor

D2 CHPL 2500

CHPL/CHPLB 2500

DATI TECNICI TECHNICAL DATA

i T2n

(n1=1400 rpm)

P1n

(n1=1400 rpm)

Pt IEC
