Features

– 7 sizes

– High transmittable torque and very compact design

– Variable in the gear ratio range

– Weight-optimized drive

– High permitted radial load at the output

– Invertible housing

– High thermal rating

– Shared oil chamber

– Areas of application: apron feeders, bucket-wheel reclaimers, boom drives, chip board plants

Advantages

– Sealing systems and lubrication variants are available to suit specific applications

– Reduced space and weight due to the use of a motor scoop or adapter

– Reduced costs as no replacement gear unit is needed (invertible housing)

– Can be used at very low temperatures

Gear unit design

Stages

Gear ratio i

Nominal torque MN2 kNm

Bevel-helical planetary gear units P-X

4 stages

160 – 550 *

100 – 500 *
