03
Electrical data
Type | CMSMB70/AP and | ||
CMP71S | CMP71M | CMP71L | |
Max. torque Nm | 19.2 | 25 1) | 25 1) |
Standstill torque Nm | 6.4 | 9.4 | 13.1 |
Mechanical data
Rated speed nN | 2 000 min-1 3 000 min-1 4 500 min-1 6 000 min-1 | |||
Spindle type | KGT 2) 32×6 | |||
Max. continuous feed force N | 5 000 | 7 500 | 10 500 | |
Peak feed force N | 18 000 | 24 000 | 24 000 | |
Stroke lengths mm | 100 / 160 / 200 / 400 / 600 / 800 / 1 000 / 1 200 | |||
Max. speed mm/s | 450 | 450 | 450 | |
1) Max. permitted torque
2) Ball screw
3.4 Accessories and options
