Modular CMSM.. electric cylinders
CMSMB50 – 71 series / AP (axially parallel)
Electrical data
Type | CMSMB63/AP and | |||
CMP63S | CMP63M | CMP63L | ||
Max. torque Nm | 11.1 | 11.1 1) | 11.1 1) | |
Standstill torque Nm | 2.9 | 5.3 | 7.1 | |
Mechanical data
Rated speed nN | 3 000 min-1 4 500 min-1 6 000 min-1 | ||
Spindle type | KGT 2) 25×6 | ||
Max. continuous feed force N | 2 100 | 3 500 | 5 000 |
Peak feed force N | 10 000 | 10 000 | 10 000 |
Stroke lengths mm | 60 / 100 / 160 / 180 / 200 / 400 / 600 | ||
Max. speed mm/s | 450 | 450 | 450 |
1) Max. permitted torque
2) Ball screw
