03
line FI FI
Project planning | Project planning is the basic requirement for safe operation of explosion-proof motors. EDRS.. and EDRE.. motors meet the defined requirements for use in potentially explosive atmospheres of the Directive 2014/34/EU (ATEX), IECEx and HazLoc-NA Division 2. A device for direct temperature monitoring in combination with the defined parameters of the frequency inverter offers the best possible protection against excessive heating caused by overload. | ||
Technical data | EDR.. motors 230 / 400 V | ||
Connection | Star | Delta | |
P kW | M Nm | M Nm | |
Category 2G / 2D / EPL b / Div. 2 | 0.25 – 37 | 1.7 – 240 | 1.7 – 240 |
Category 3G / 3D / EPL c / Div. 2 | |||
Category 3D with MOVIMOT | 0.25 – 3.0 | 1.7 – 20,5 | 1.2 – 9.9 |
For frequency inverter operation, there is no reduced load value in relation to the nominal line torque to ensure thermally safe operation as is often usual.
