Features

– Their high level of efficiency makes them energy-saving angular drives

– High-endurance gearing makes for high-torque, wear-free drives

– Long maintenance-free service life

– Also available with reduced backlash

– Possible variants:

- Foot- or flange-mounted design

- B5 or B14 flange

- Solid or hollow shaft

- Hollow shaft with keyed connection, shrink disk, splining or TorqLOC

Gear unit ratio

i

3.98 – 197.37

Gear unit ratio – compound gear units

i

94 – 32 625

Max. output torque

Nm

200 – 50 000 *

Motor power range

(mounting via AM motor adapter)

kW

0.12 – 90
