Features

– Helical gear units with extended output bearing hub

– Specifically designed for agitating applications

– Allow for high overhung and axial loads as well as bending moments

Gear unit ratio

i

4.29 – 289.74

Gear unit ratio – compound gear units

I

134 – 27 001

Max. output torque

Nm

450 – 18 000

Motor power range

(mounting via AM motor adapter)

kW

0.12 – 90

Features

– Slim design for limited installation space

– Also available with reduced backlash

– Particularly suited for materials handling and process engineering applications

– Possible variants:

Foot- or flange-mounted design, B5 or B14 flange, Solid or hollow shaft, hollow shaft with keyed connection, shrink disk, splining or TorqLOC

Gear unit ratio

i

3.77 – 281.71

Gear unit ratio – compound gear units

i

87 – 31 434

Max. output torque

Nm

130 – 18 000 *

Motor power range

(mounting via AM motor adapter)

kW

0.12 – 90
