CH06FC 1 CH06FC 2
CH06F1 CH06F2
CH 07 - PERFORMANCE WITH 4-POLE MOTORS 1400 REVS. INPUT
TYPE i=ratio n2 r/min Kw=P1 Nm=T2 f.s. Possible types of motor connections
7 | 200 | 4 | 170 | 1.1 | 100/90 | B5/B14 | ||
10 | 140 | 3 | 175 | 1.3 | 100/90 | B5/B14 | ||
15 | 93 | 3 | 250 | 1.0 | 100/90 | B5/B14 | ||
20 | 70 | 2.20 | 240 | 1.0 | 100/90 | B5/B14 | ||
25 | 56 | 1.85 | 250 | 1.0 | 90/80 | B5/B14 | ||
30 | 47 | 1.50 | 230 | 1.2 | 90/80 | B5/B14 | ||
40 | 35 | 1.1 | 215 | 1.2 | 90/80 | B5/B14 | ||
50 | 28 | 1.1 | 220 | 0.9 | 90/80 | B5/B14 | ||
60 | 23 | 0.75 | 200 | 1.0 | 90/80 | B5/B14 | ||
80 | 17 | 0.55 | 180 | 1.0 | 80/71 | B5/B14 | * | |
100 | 14 | 0.37 | 140 | 1.1 | 80/71 | B5/B14 | * | |
*71 solo B5 | ||||||||
Weight Kg 9,2 |
CH 07
