CH 04 - PERFORMANCE WITH 4-POLE MOTORS 1400 REVS. INPUT
TYPE i=ratio n2 r/min Kw=P1 Nm=T2 f.s. Possible types of motor connections
7 | 200 | 0.55* | 22 | 1.4 | 71/63 | B5/B14 | |
10 | 140 | 0.55* | 30 | 1.0 | 71/63 | B5/B14 | |
14 | 100 | 0.37 | 29 | 1.0 | 71/63 | B5/B14 | |
20 | 70 | 0.37 | 38 | 1.0 | 71/63 | B5/B14 | |
28 | 50 | 0.37 | 40 | 0.9 | 71/63 | B5/B14 | |
35 | 40 | 0.25 | 41 | 0.9 | 71/63 | B5/B14 | |
46 | 30 | 0.18 | 37 | 1.0 | 63 | B5/B14 | |
60 | 23 | 0.18 | 37 | 0.9 | 63 | B5/B14 | |
70 | 20 | 0.12 | 33 | 0.9 | 63 | B5/B14 | |
100 | 14 | 0.12 | 30 | 0.9 | 63 | B5/B14 | |
Weight Kg 2,1 |
CH 04
* Motors 71 gr.
