TORQUE ARM
TYPE CHT MV 25* | I 70 | R 15 | F 17.5 | H 14 | Ø E 8 | A 33.5 | B 118.5 | Ø C 55 | Ø d 7 | Ø P 45 | N° 4 | Weight for kit kg 0.17 | |
CHT MV 30* | 85 | 15 | 24 | 14 | 8 | 38 | 138 | 65 | 7 | 55 | 8 | 0.18 | |
CHT MV 40 | 100 | 18 | 31.5 | 14 | 10 | 44 | 162 | 75 | 7 | 60 | 8 | 0.24 | |
CHT MV 50 | 100 | 18 | 38.5 | 14 | 10 | 50 | 168 | 85 | 9 | 70 | 8 | 0.27 | |
CHT MV 63 | 150 | 18 | 49 | 14 | 10 | 55 | 223 | 95 | 9 | 80 | 8 | 0.57 | |
CHT MV 75 | 200 | 30 | 47.5 | 25 | 20 | 70 | 300 | 115 | 9 | 95 | 8 | 1.10 | |
CHT MV 90 | 200 | 30 | 57.5 | 25 | 20 | 80 | 310 | 130 | 11 | 110 | 8 | 1.26 | |
CHT MV 110 | 250 | 35 | 62 | 30 | 25 | 100 | 385 | 165 | 11 | 130 | 8 | 1.92 | |
CHT MV 130 | 250 | 35 | 69 | 30 | 25 | 125 | 410 | 215 | 14 | 180 | 8 | 2.23 | |
CHT MV 150 * Without vibration re | 250 sistant bushi | 35 ng | 84 | 30 | 25 | 125 | 410 | ø C | 215 | 14 | 180 ø C | 8 | 2.23 |
ø P
ø P
The anchoring point of the torque arm is equipped with a vibration resistant bushing.
A
B I
ø E
F H
CHT MV 25
A 10°
10°
ø d ø d
B I
R R
