RECOMMENDED OILS
AGIP | A.T.F. DEXRON |
ESSO | A.T.F. DEXRON |
SHELL | A.T.F. DEXRON |
BP | A.T.F. DEXRON |
G X
G3 VR1 VR
VS
VC B
VF
b
P
M N
Y
t
VL
f
H
d
D
D1 M1
I
T K E
B D(j6) E | G | G3 | H | I | M M1 N | d D1 | P | T | K | VC VF | VL VR VR1 VS b | f | t | kg | |||||||||||
CHV 02 | 23 | 11 | 50 | 112.5 | 64.5 | 70 | 72 | 115 | 60 | 95 | 9 | M6 | 140 | 3.5 | 46 | 71 | 111 | 78 | 110 | 110 | 85 | 4 | M5 | 12.5 | 3.4 |
CHV 05 | 30 | 14 | 40 | 110 | 74 | 80 | 90 | 130 | 76 | 110 | 9 | M8 | 160 | 3.5 | 52.5 | 71 | 123 | 90 | 110 | 110 | 85 | 5 | M6 | 16 | 4.7 |
CHV 10 | 40 | 19 | 58 | 139 | 85.5 | 100 | 98 | 165 | 84 | 130 | 11 | M8 | 200 | 3.5 | 60 | 79 | 140 | 107 | 120 | 120 | 110 | 6 | M6 | 21.5 | 7.8 |
CHV 20 | 50 | 24 | - | 188 | 115 | 126 | 241 | 165 | - | 130 | 11 | - | 200 | 3.5 | - | - | 144 | 122 | 150 | - | 110 | 8 | M8 | 27 | 31 |
CHV 30 | 60 | 28 | - | 222 | 131 | 150 | 270 | 215 | - | 180 | 15 | - | 250 | 4 | - | - | 188 | 150 | 160 | - | 110 | 8 | M10 | 33 | 55 |
CHV 50 | 60 | 28 | - | 222 | 131 | 150 | 270 | 215 | - | 180 | 15 | - | 250 | 4 | - | - | 188 | 150 | 160 | - | 110 | 8 | M10 | 33 | 57 |
