LUBRICATION
Speed variators are supplied with lubrication oil for assembly position B5, for other positions it will be necessary to add oil, see following table.
CHV | 02 | 05 | 10 | 20 | 30 | 50 |
B5 | 0.13 | 0.15 | 0.33 | 0.8 | 1.20 | 1.20 |
V1 | 0.3 | 0.4 | 0.85 | 1.40 | 2.15 | 2.15 |
V3 | 0.2 | 0.25 | 0.45 | 0.90 | 1.30 | 1.30 |
138
OIL QUANTITY Kg
CHV - PERFORMANCES WITH 4 POLES MOTORS - LUBRICATION
