03
Technical data
Frequency inverter operation / 50 Hz
Constant torque from 300 to 1 500 min-1 CT 1:5
Design | Energy efficiency class | Size | Power rating PN kW |
DRE..J | IE2 | 71S – 100M | 0.37 – 4.0 |
DRP..J | IE3 | 71S – 100L | 0.37 – 4.0 |
DRU..J | IE4 | 71S – 100L | 0.18 – 3.0 |
FI operation / 87 Hz
Constant torque from 300 to 2 610 min-1 CT 1:8:7
Design | Energy efficiency class | Size | Power rating PN kW |
DRE..J | – * | 71S – 100M | 0.55 – 5.5 |
DRP..J | – * | 71S – 100L | 0.55 – 5.5 |
DRU..J | – * | 71S – 100L | 0.25 – 4.0 |
Line operation / 50 Hz
Nominal speed: 1 500 min-1
Design | Energy efficiency class | Size | Power rating PN kW |
DRE..J | IE2 | 71S – 100M | 0.37 – 4.0 |
DRP..J | IE3 | 71S – 100L | 0.37 – 4.0 |
DRU..J | IE4 | 71S – 100L | 0.18 – 3.0 |
* IE classification as per IEC 60034-30-1:2014 is only applicable to 50 Hz or 60 Hz
3.1 AC motors
