Direct motor mounting

Positive direct motor mounting (without terminal adapter) of the CMP.. and CM.. servomotor series from SEW-EURODRIVE

Motor adapter

EPH motor adapter for PS.F and PS.C planetary servo gear units, ECH motor adapter for PS.C planetary servo gear units and EBH motor adapter for BS.F helical-bevel servo gear units

Reduced backlash

Optionally for PS.F planetary servo gear units and BS.F helical-bevel servo gear units with significantly smaller rotational clearance

Minimized rotational clearance

Optionally for PS.F planetary servo gear units with even more reduced rotational clearance

Features

– For use in areas subject to frequent cleaning:

- Intralogistics

- Hygienic applications

- Food and beverage industry

- Pharmaceutical industry

- Permanently humid environments

– Low maintenance with long service life

– Efficiency-optimized gear units

– Available as KES37 helical-bevel gearmotors and RES37 helical gearmotors

– High-quality stainless steel is used

– Easy-to-clean surface thanks to special housing design

– High grade resistance to acid and alkaline

– Recesses where dirt and liquid can accumulate were eliminated as far as possible

– IEC and NEMA adapters, also made of stainless steel, allow for variable motor mounting

Type

Max. output torque Nm

Gear unit ratio i

KES37

200

3.98 – 106.38

RES37

200

3.41 – 134.83

Features

– Compact, space-saving design as gearmotor for direct mounting

– The entirely stainless steel design efficiently prevents all forms of corrosion

– Directly mounted stainless steel motors are designed without fan so they can be cleaned easily and reliably

Motor power range kW

0.37 – 0.75

(Higher power ratings for adapter mounting are available upon request)

Certified gear units

Certified protection types

RX, R, RM series helical gear units

– For the European market: Gear units comply with Directive 2014/34/EU (ATEX), equipment group II, equipment category 2, II2GD design

– Also accepted in China

– Comply with TR CU, the Eurasian Custom Union Russia/Belarus/Kazakhstan/Armenia in combination with Ex EAC certificate (successor to GOST-R)

– Protection type „c“: Protected by safe construction (design safety) EN 13463-1 and -5

– Protection type „k“: Protected by liquid immersion, EN13463-1 and -8

F series parallel-shaft helical gear units

K series helical-bevel gear units

S series helical-worm gear units

W series SPIROPLAN right-angle gear units

Certified gear units

Certified protection types

PS.F planetary servo gear units

– For the European market: Gear units comply with Directive 2014/34/EU (ATEX), equipment group II, equipment category 2, II2GD design

– Also accepted in China

– Comply with TR CU, the Eurasian Custom Union Russia/Belarus/Kazakhstan/Armenia in combination with Ex EAC certificate (suc- cessor to GOST-R)

– Protection type „c“: Protected by safe construction (design safety) EN 13463-1 and -5

– Protection type „k“: Protected by liquid immersion, EN13463-1 and -8

BS.F helical-bevel servo gear units

Features

To optimally protect motors and gear units that are subject to severe environmental influences, SEW-EURODRIVE offers possibilities to increase the resistance of highly stressed surfaces.

KS corrosion protection

Measures to increase the resistance to corrosion:

– All retaining screws that are loosened during inspection or maintenance work are made of stainless steel.

– Nameplates are made of stainless steel and various motor parts are coated with a finishing varnish

– The flange contact surfaces and shaft ends are treated with a temporary rust preventive

– In addition, clamping straps are used for brakemotors

OS surface protection

In addition to the standard surface protection, motors and gear units are optionally available with surface protection OS1, OS2, OS3 or OS4. This makes the gearmotors well equipped for operation under various ambient conditions.
