Features

– Planetary servo gear units

– Designed for nominal torques between 30 Nm and 320 Nm

– Provide the basis for diverse, dynamic, and above all, cost-optimized drive solutions

– Compact, lightweight design

– Any mounting position

– Life-long lubrication

– Four output variants:

- PSC = B5 output, solid shaft

- PSKC = B5 output, solid shaft with key

- PSCZ = B14 output flange, solid shaft

- PSKCZ = B14 output flange, solid shaft with key

Type

Size

single-stage / two-stage

Torque class Nm

Overhung load range

N

Gear unit ratios i

Rotational clearance ‘ (single-stage/two-stage)

Standard

PS(K)C PS(K)CZ

221 / 222

30

1 170 – 2 000

single-stage 31), 5, 7, 10

two-stage 151), 211), 25,

301), 35, 49, 50,

70, 100

10‘ / 15‘

321 / 322

65

1 710 – 4 000

521 / 522

160

2 900 – 6 750

621 / 622

320

5 390 – 11 000
