Standard CMS.. electric cylinders / with grease lubrication
CMS71 series (with grease lubrication)
Features – Equipped with permanent magnet rotors
– Precise, powerful and fast
– Combined with drive electronics from SEW-EURODRIVE, this series makes for energy-efficient drive solutions that ensure a high level of process reliability and that can be easily integrated into existing automation systems
Electrical data
Type | CMS71L | ||
Max. torque Nm | 31.4 | 22.1 1) | 24.4 1) |
Standstill torque Nm | 9.5 | ||
07
Mechanical data
Rated speed nN | 2 000 min-1 3 000 min-1 4 500 min-1 | |||
Screw type | KGT2) 32x10 | KGT2) 32x6 | PGT3) 24x5 | |
Max. continuous feed force 4) N | 3 600 | 6 700 | 7 200 | |
Peak feed force N | 17 000 | 20 000 | 15 000 20 000 5) | 20 000 |
Stroke lengths mm | 200 | 200 | 350 | 200 |
Max. speed mm/s | 500 | 300 | 200 | 250 |
1) Maximum permitted torque
2) Ball screw
3) Planetary roller screw
4) Depending on average travel speed
5) In case of tensile loads
