i T2n

(daNm)

OUT IN

18002 13.0 ÷ 30.0 1146.7 ÷ 1314.8

18003 53.8 ÷ 180.2 1146.7 ÷ 1314.8

18004 348.6 ÷ 1216.4 1146.7 ÷ 1314.8

Ø100

Ø120

80X74

100X94 DIN 5482

80X74 DIN 5482

Ø42 Ø65

Electric Motor

Hydraulic Motor

Worm gearboxes

CHPL

Brake

i T2n

(daNm)

OUT IN

18002 10.9 ÷ 20.0 1146.7 ÷ 1314.8

18003 54.4 ÷ 163.3 1146.7 ÷ 1314.8

18004 185.8 ÷ 981.2 1146.7 ÷ 1314.8

Ø100

Ø120

80X74

100X94 DIN 5482

80X74 DIN 5482

Ø42 Ø65

Electric Motor

Brake

CHPLB

Hydraulic Motor

I2 CHPL 18000

CHPL/CHPLB 18000

DATI TECNICI TECHNICAL DATA

i T2n

(n1=1400 rpm)

P1n

(n1=1400 rpm)

Pt IEC
