DIMENSIONI CFS CFS DIMENSIONS
CHPL 7000 CFS - Riduttore a vite senza fine CHM in entrata CHPL 7000 CFS - CHM input worm gearboxes
CHM 50 CHM 63
CHPL
LV I H M N LV I H M N
7001 - -
LV
ØC M N
ØAE
7002 435
7003 483
50 110 60 80
444.5
492.5
63 135 72 95
7004 531 540.5
CHPL
I
H
CHM 75 CHM 90 CHM 110
7001 | - | - 388 | |||
7002 | 423.5 | 433.5 | 461 | ||
7003 | 471.5 75 161 86 112.5 | 481.5 90 | 193 103 129.5 | - ØC | p. |
7004 | 519.5 | 529.5 | - ØAE | P6 | |
LV I H M N LV I H M N LV I H M N
110 237.5 127.5 160
CHPLB 7000 CFS - Flange motori IEC CHPLB 7000 CFS - IEC Motor flanges
CHPLB | IEC 63 | IEC 71 | IEC 80 | IEC 90 | ||||||||||||
L | LP | P | ØD | L | LP | P | ØD | L | LP | P | ØD | L | LP | P | ØD | |
7002 | 338 | 276 | 36 | 140 | 338 | 276 | 36 | 160 | 338 | 296 | 56 | 200 | 338 | 296 | 56 | 200 |
7003 | 384.5 | 196 | 384.5 | 196 | 384.5 | 216 | 384.5 | 216 | ||||||||
7004 | 432.5 | 432.5 | 432.5 | 432.5 | ||||||||||||
L p.
P4
P
LP
ØD
CHPLB | IEC 100 | IEC 112 | IEC 132 | IEC 160 | IEC 180 | |||||||||||||||
L | LP | P | ØD | L | LP | P | ØD | L | LP | P | ØD | L | LP | P | ØD | L | LP | P | ØD | |
7002 | 338 | 306 | 66 | 250 | 338 | 306 | 66 | 250 | 338 | 340 | 100 | 300 | 338 | 379 | 139 | 350 | 338 | 379 | 139 | 350 |
7003 | 384.5 | 226 | 384.5 | 226 | 384.5 | 260 | 384.5 | 299 | - | |||||||||||
7004 | 432.5 | 432.5 | 432.5 | - | - | |||||||||||||||
140 (7002)
93 (7003 / 4)
76 (7002)
66.5 (7003 / 4)
CHPLB 7000 CFS - Alberi maschi entrata CHPL 7000 CFS - Male input shafts
L p.
P7
E
LE
LT
ØE
CHPLB | CM42 | CM65 | CP65 | ||||||||||||
L | LT | T | LE | ØE | L | LT | T | LE | ØE | L | LT | T | LE | ØE | |
7002 | 338 | 333 | 93 | 82 | 42 h6 | 338 | 377.5 | 121.5 | 105 | 65 h6 | 338 | 409 | 153 | 105 | 65 h6 |
7003 | 384.5 | 253 | 384.5 | 297.5 | 384.5 | 329 | |||||||||
7004 | 432.5 | 432.5 | 432.5 | ||||||||||||
140 (7002)
93 (7003 / 4)
76 (7002)
66.5 (7003 / 4)
F12
