CHE..
CHR..
CHRE..
CH 06/07/08 DESIGNATION
TYPE (1) | SIZE | VERSION | FLANGE POS. (2) | i | M.M.F. | MOUNT. POS. |
CH | 06 | FC | 1 | RATIO SEE | 100B5 | UNIVERSALE |
CHR | 07 | F | 2 | 100B14 | ||
CHE | 08 | (3) | 90B5 | |||
CHRE | PAGE | 90B14 | ||||
70-71-72 | 80B5 | |||||
80B14 | ||||||
71B5 | ||||||
71B14 |
ORDER EXAMPLE
CH 06 FC 1 19 90 B5
If the motor is also required, please specify: Size es. 90 L4
Power es. Kw 1.5
Poles es. 4
Voltage es. V230/400 Frequency es. 50 Hz Flange es. B5
68
1) see page 67
2) see page 69
3) lack of instructions indicates that the gear is not equipped with an output flange
CH 06/07/08 DESIGNATION - ORDER EXAMPLE
