B3
TERMINAL BOX POSITION
4 2 N.B. The position of the terminal box always refers to
the B3 position.
3
TYPE i=ratio n2 r/min Kw=P1 Nm=T2 f.s. Possible types of motor connections
7 | 200 | 0.22 | 8 | 1.8 | 63/56 | B5/B14 | |
10 | 140 | 0.22 | 11 | 1.4 | 63/56 | B5/B14 | |
15 | 93 | 0.22 | 16 | 1.0 | 63/56 | B5/B14 | |
CH 03 20 | 70 | 0.22 | 20 | 0.9 | 63/56 | B5/B14 | |
30 | 47 | 0.18 | 22 | 0.8 | 63/56 | B5/B14 | |
40 | 35 | 0.12 | 18 | 1.0 | 63/56 | B5/B14 | |
60 | 23 | 0.09 | 18 | 1.0 | 63/56 | B5/B14 | |
70 | 20 | 0.09 | 15 | 0.9 | 56 | B5/B14 | |
Weight Kg 1 | |||||||
DIMENSIONS
55 | |
16 |
