ORDER EXAMPLE

CHM/CHM 040/090 FA(5) 2(5) 500 OAD 63 B14 V5

46

If the motor is also required, please specify: Size es. 63 B4

Power es. Kw 0.18

CHM/CHMR/CHME/CHMRE DESIGNATION - ORDER EXAMPLE

Poles es. 4

Voltage es. V230/400 Frequency es. 50 Hz Flange es. B14

N.B. From size 25 to 63 the gears are always supplied in the Universal position and can therefore be mounted in any position, from

size 75 to size 130 if the position required differs from B3 it must be specified.

In particular, in the event that a gear in position B3 is to be mounted in positions V5 or V6, the bearing positioned in the upper side

must be lubricated using suitable grease that ensures proper lubrication. We have tested Tecnolubeseal POLYMER 400/2 grease.

1) see page 48

2) see from page 31 to page 40

3) see page 30

4) see page 47

5) lack of instructions indicates that the gear is not equipped with an output flange.

Quantity, availability and prices with Chiaravalli B2B
