CHMRE
CHMR
The worm gears made by Chiaravalli Group S.p.A. are square and are considerably versatile for mounting. The machining of the components, carried out using numeric control machines, guarantees maximum precision for the restricted tolerances, producing a product that will remain reliable over time.
The groups are constructed with aluminium casings from sizes 025 to 090, while the sizes 110, 130 and 150 are made from cast iron.
All of the bodies are painted with RAL 9022 aluminium colour to protect the parts from aging and to give better protection against microblowholes that may be present in the aluminium.
The gears are supplied with at least one filling plug that is also used during testing to check for possible leaks.
A connection flange allows two gears to be combined in order to obtain high gear ratios.
Four sizes of CHPC pre-stage gears are available to pair with the gears; these are also constructed in aluminium and are painted like the worm gears.
All of the groups are supplied with a lubricant whose characteristics are described in the following table.
