SPARE PART LIST

140

1 OUTPUT SHAFT

2 PLANET SUPPORT

3 SLIDE BLOCK

4 REGULATING ORBIT

5 BALL RING

6 MOVING OUTER PLANETARY ORBIT

7 PLANET WHEEL

8 OPERATING BOX

9 FIXED OUTER PLANETARY ORBIT

10 FIXED INFERIOR PLANETARY ORBIT

11 MOVING INFERIOR PLANETARY ORBIT

12 BUTTERFLY SPRING

13 MOTOR SHAFT

1 2 3 4 5 6 7 8 9 10 11 12

CHV - USE AND MAINTENANCE - SPARE PART LIST

13
