LUBRICANT FILL QUANTITY
The specified fill quantities are recomended values. The precise values vary depending on the number of stages and gear ratio. The following tables show guide values for lubricant fill quantities in relation to the mounting position (B3, B6, B7...)
92
fill quantity in liters
size B3 B6 B7 B8 V5 V6
CHO 52 | 0.22 | 0 | .20 | 0.13 | 0.15 | 0. | 25 | 0.14 | ||||||
CHO 53 | 0.07 | 0 | .04 | 0.04 | 0.05 | 0. | 08 | 0.09 | ||||||
CHO 62 | 0.38 | 0 | .35 | 0.25 | 0.26 | 0. | 44 | 0.25 | ||||||
CHO 63 | 0.07 | 0 | .04 | 0.04 | 0.05 | 0. | 08 | 0.09 | ||||||
CHO 72 | 0.66 | 0 | .60 | 0.45 | 0.48 | 0. | 78 | 0.47 | ||||||
CHO 73 | 0.13 | 0 | .09 | 0.09 | 0.09 | 0. | 15 | 0.17 | ||||||
CHO 82 | 1.15 | 0 | .93 | 0.70 | 0.74 | 1. | 25 | 0.75 | ||||||
CHO 83 | 0.13 | 0 | .09 | 0.09 | 0.09 | 0. | 15 | 0.17 |
CHO gearboxes are supplied complete with mineral oil for mounting position B3.
The pre-stage used for third stage is lubricated with syntetic oil and it does not need the breather plug.
CHO LUBRICATION
Quantity, availability and prices with Chiaravalli B2B
1 For gear units, first oil change should be after about 300 hour (run-in period).
Never mix the synthetic oil and mineral oil together.
2 Every 3000 working time, at least every 6 months, you have to check the oil and oil level, the seals visually for leakage. For IEC input gear units, the elastomer should be tested or replaced
if necessary.
3 Dependong on the operating conditions every 3 years at the latest for inspection is needed.
Then change the mineral oil and replace the bearing grease.
4 Depending on the operating conditions, change the oil seals.
5 Verify that the coupling used to connect the motor is always greased to avoid risks of wear.
