ORDER EXAMPLE
CH/CH 03/05P FA 2 315 OBS 56B14
If the motor is also required, please specify:
Size es. 56 C4
Power es. Kw 0.09
Poles es. 4
Voltage es. V230/400
Frequency es. 50 Hz
Flange es. B14
1) see page 63 and 69
2) lack of instructions indicates that the gear is not equipped with an output flange. In this case the group can be fixed on feet CH/CH or be swinging CH/CH..P
3) lack of instructions indicates that the gear is not equipped with an output flange.
