CH07FE1 CH07FE2
CH07F2
ø110 H8 ø160
ø130
45∞
4-ø11 5
12
85
TYPE i=ratio n2 r/min Kw=P1 Nm=T2 f.s. Possible types of motor connections
7 | 200 | 4 | 170 | 1.5 | 112/100/90 | B5/B14 | ||
10 | 140 | 4 | 240 | 1.2 | 112/100/90 | B5/B14 | ||
15 | 93 | 4 | 350 | 0.9 | 112/100/90 | B5/B14 | ||
20 | 70 | 3.00 | 340 | 0.9 | 100/90 | B5/B14 | ||
CH 08 | 23 | 61 | 2.20 | 280 | 1.1 | 100/90 | B5/B14 | |
30 | 47 | 2.20 | 340 | 1.1 | 100/90 | B5/B14 | ||
40 | 35 | 1.85 | 340 | 0.9 | 90/80 | B5/B14 | ||
46 | 30 | 1.5 | 340 | 1.0 | 90/80 | B5/B14 | ||
56 | 25 | 1.1 | 290 | 1.0 | 90/80 | B5/B14 | ||
64 | 22 | 1.1 | 290 | 0.9 | 90/80 | B5/B14 | ||
80 | 17 | 0.75 | 260 | 1.0 | 90/80 | B5/B14 | ||
100 | 14 | 0.55 | 220 | 1.0 | 80 | B5/B14 | ||
Weight Kg 12,2 |
